power amplifiers price
840-930MHz 50W Power Noise Amplifiers
Material：钨钢
Delivery：3~7天
Description：840-930MHz 50W Power Noise Amplifiers
Specifications：840-930MHz 50W Power Noise Amplifiers
Online Consultation
Delivery：3~7天
Description：840-930MHz 50W Power Noise Amplifiers
Specifications：840-930MHz 50W Power Noise Amplifiers
- Model：
- .RF technical parameters：
- Dimension：
50W power noise amplifier
PA2400-2500M-50G1
|
Item name |
Technical parameters |
|
working frequency |
2400-2500MHz |
|
Saturated power output |
47±1dBm |
|
Gain |
45±1dB |
|
In-band flatness |
≤±1dB |
|
Input and output standing |
≤1.5 |
|
Out-of-band spurs |
9kHz～1GHz：≤-36dBm/30kHz 1GHz～12.75GHz：≤-30dBm/30KHz |
|
Operating Voltage |
DC+28V |
|
Working current |
≤3.5A |
|
Power supply interface |
Red &Black power cord |
|
RF port |
SMA-KFD |
|
Amplifier size |
111*37.2*18mm |
|
Operating temperature |
-10～+55℃ |
|
Relative humidity |
5%～95%，No condensation |
|
Storage temperature |
-25～+65℃ |
